Product Description

Click here for Best Deals

30a solar charge controller lcd display 12v 360w solar panel 24v 720w solar panels light timer control solar regulator solar30

Solar30 30A Solar Charge Controller 12V 24V auto switch Lighting Controller


Package including:
1.  1PCS  30A solar controller
2   1 PCS   User’  manual
3   1 PCS temp sensor


Ideal for
For 12V PV system: 24V for Max input,400W Solar Panel.
For 24V PV system :48V for Max input,800W Solar Panel

This controller has Light and Timer control Function
Light control:When daylight starts to occur then the light source goes off. Meanwhile the Solar Panels will charge the batteries. when there is no sunlight the garden light will switch on.
Time control:There is an eight hours time control,that means it will go off when the Lights automatically switch off after 0-15 hours.
This Solar30 Solar controller is a kind of intelligent and multifunctional solar charge controller. These serial products adopt customized LCD display screen, which makes the operation on the interface rather convenient. All the controlling parameters can be reset flexibly to satisfy your different needs.

Function:
– Visual LCD graphic symbol – Brief key operation
– Grade auto switch of system voltage – Intelligent PWM Charging Mode
– Auto temperature compensation – Adjustable charging & discharging parameter
– Settable working modes of loads – Accumulative function of charging & discharging AH
– Overloading & short-circuit protection – Battery reversed protection
– Delayed auto restart after overloading protection – Protection for battery low voltage
– Protection for battery back discharging



Installation Data:

Installtion cable area

7# AWG ( 16mm2)

Operation temperature

-10 °C~ 60 °C

storage temperature

-30 °C~ 70 °C

Humidity requirement

<90% , no condensation

Size

90mm*188mm*48mm

Mounting hole spacing

60 mm 178 mm –5

Weight

360g

Data Sheet
Model Solar30
Rated Current 30A
Rated Voltage 12V/24V
Maximum Voltage of solar panel <48V
Float Voltage 13.8V/27.6V
Low Voltage Disconnection 10.7V/21.4V
Low Voltage Reconnection 12.5V/25V
No load loss <30mA
loop voltage drop <200mV
Charging Mode PMW Mode
Temperature Compensation -4mV/Cell
 °C



1wholesale

1.Feel free to contact us via Ali Wangwangali,we will give you competitive price .


2.We accept OEM ODM


working time
1payment

1.We accept the following payment methods: Paypal ,T/T,West-Union,Credit Card

2.Aliexpress need 12-24 hours to verify your payment, please be patient.



Payment


1shipment


1.We will send in 1- 3 days.

2.We ship every order with their Tracking NO.

3.Make sure you provide the correct delivery address and telphone number!

4.If you need this order in urgent, please choose EMS,DHL, Fedex ,UPS or other Express as shipping way. Thank you!

5.The average delivery time is about 15 to 35 days. But sometimes it takes longer due to custom issue or other problems.

Shipping time

1 Guarantee

1 Year Warranty

1return

Return

1feedback

feedback





start05393943

See all Bestsellers

Additional Information

Is_customized

Yes

Application

Charger Controller

Maximum Current

30A

Brand Name

y-solar

Model Number

S30

Rated Voltage

12V/24V

Application:

Solar System Controller

Maximum Current:

30A

Max Input Power

For 12V PV system: 24V For 24V PV system :48V

Model Number:

Solar30

Rated Voltage

12V24V auto work

Charging Mode

PMW Mode

Load Control Mode

Light and timer control

Float Voltage

13.8V/27.6V

Low Voltage Disconnection

10.7V/21.4V

Low Voltage Reconnection

12.5V/25V
