Product Description
1000w new grid tie inverter on grid system for solar panel pv dc 12v/24v to ac 220v/110v+10% pure sine wave mppt function
1000w New Grid Tie Inverter on grid System
For Solar panel PV
DC 12V/24v
to AC 220V/110v+10%
Pure Sine Wave MPPT Function
Smart Grid Tie Micro inverter Technical Parameters:
(Suit for 36 cells solar panel which Vmp is 17-18V as well as Voc is 21-22V.)
(Suit for 36 cells solar panel which Vmp is 17-18V as well as Voc is 21-22V.)
Features:
- Generates pure Sine Wave
- Automatic power adjustment
- Constant Power Output
- Low distortion output on all ranges
- Allow different Power factor from loads
- Compact and light weight design
- Maximum Power Point Tracking (MPPT) – optimize power output
- Plug and Play Design, simply plug into an outlet (GFI), no hard-wiring
- Stackable (connect in parallel for higher output)
- Aluminum enclosure will act as heat sink to help dissipate heat
- Simple and safe installation
- Island protection: Inverter will shut down during black outs.
- Grid-Tied – sell green power directly back to the grid at a premium rate
- Size: 210*165*53mm
- Output Power: 600W – 1000W
- Input Voltage: 10.5V~28V DC
- Output Voltage: 90V-140V
- (depends on your location)
- Certifications: CE, RoHS
Main Technical Specification
|
Grid-inverter Type
|
1000W
|
|
Recommended Maximum PV Power
|
Ppv=1250Wp
|
|
DC Maximum Input Power
|
PDC.max=1100W
|
|
DC Maximum Voltage
|
VpvDC30.2VDC
|
|
PV MPPT DC Voltage Range
|
Vpv 10.5V~28VDC
|
|
Peak Inverter Efficiency
|
max>94%
|
|
MPPT Efficiency
|
99%
|
|
PV Maximum Input Current
|
Ipv.max30A
|
|
Rating Output Power
|
1000W
|
|
Maximum Output Power
|
1250W
|
|
Reverse Polarity Protection
|
Fuse
|
|
AC Normal Voltage Range
|
90V-140/180~260VAC
|
|
AC Frequency
|
45Hz~53Hz/55Hz~63Hz
|
|
Inverter Output Current Total Harmonic Distortion
|
THDIAC <5%
|
|
Phaseshift
|
<1%
|
|
Island Effect Protection
|
VAC;f AC
|
|
Inverter Output Shorting Protection
|
Current Limiting
|
|
Disaplay
|
LED
|
|
Standby Power Consumption
|
<8W
|
|
Nighttime Power Consumption
|
<1W
|
|
Ambient Temperature Range
|
-25~60 degree
|
|
Ambient Humidity
|
0~99%(Indoor Type Design)
|
|
Waterproof
|
Indoor Type Design
|
|
Eelectromagnetic Compatibility
|
EN50081.part1 EN50082.part1
|
|
Power Network Disturbance
|
EN61000-3-2
|
|
Power Network Detection
|
DIN VDE 126
|
|
Protection
|
Islanding; Short-circuit; converse connection; Low Voltage; Over Voltage; Over temperature Protection
|
|
Work Temperature
|
-25-80 degree
|
|
Work Humidity
|
0%~90%RH non-condensing
|
|
Grade of Waterproof
|
Indoor design
|
|
Show
|
1 Red and 1 Green
|
|
Cooling
|
Fan
|
|
Stand-by Power
|
2-3W
|
|
EMC
|
EN61000-6-3:2007 EN61000-6-1:2007
|
|
Grid Disturbance
|
EN 50178+EN 62109-1+VDE0126-1-12
|
|
Grid Detection
|
DIN VDE 1026 UL1741
|
|
Certificate
|
CE
|
Kindest note: When you order this type inverter, please leave message to us. output AC voltage(110v/220v or other voltage) ;Socket type (European or American plug plug or other type).
